HARTING09561515513Steckverbinder, D-Sub
Conn D-Sub SKT 15 POS 1.14mm Solder ST Thru-Hole 15 Terminal 1 Port
| Compliant with Exemption | |
| EAR99 | |
| Active | |
| 8536.69.40.40 | |
| SVHC | Yes |
| SVHC überschreitet Schwellenwert | Yes |
| Automotive | No |
| PPAP | No |
| D-Sub | |
| RCP | |
| 15 | |
| 15 | |
| 3 | |
| Solder | |
| 1.14 | |
| Straight | |
| SKT | |
| 2 | |
| 5000 | |
| 20 | |
| -40 | |
| 85 | |
| 500 | |
| Steel | |
| Nickel | |
| E | |
| No | |
| 0.002 | |
| 30.81 | |
| 12.55 | |
| 12.7 | |
| Noble Metal Over Nickel | |
| Copper Alloy | |
| Through Hole |
The high density d-sub 09561515513 DVI connector from Harting is ideal for communicating with any serial connections you have. It has a straight body orientation. This socket type connector has 15 socket type contacts. Its pitch is 2.29 mm. This 3-row connector has a single port. 09561515513 is housed in polybutylene terephthalate. This product is 31.3 mm long, 7.25 mm tall and 12.93 mm deep. Its 15 terminals use the solder termination method.
